Other features | Advanced processor features | Intel 64 |
Processor special features | Intel VT-x with Extended Page Tables (EPT) | Tak |
| Intel Demand Based Switching | Tak |
| Intel Virtualization Technology | VT-d, VT-x |
| Intel Hyper-Threading Technology | Tak |
| Intel Turbo Boost Technology | Tak |
| Intel vPro Technology | Tak |
| Intel Flex Memory Access | Tak |
| Intel AES New Instructions | Tak |
| Enhanced Intel SpeedStep Technology | Tak |
| Intel Trusted Execution Technology | Tak |
Technical details | CPU configuration (max) | 2 |
| Embedded options available | Nie |
| Graphics & IMC lithography | 32 nanometers |
| Package size | 52.5 x 45 millimeter |
| Supported instruction sets | AVX |
| PCI Express slots version | 3.0 |
| Execute Disable Bit | Tak |
| Idle States | Tak |
| Thermal Monitoring Technologies | Tak |
Operational conditions | Tcase | 73 degrees Celcium |
Power | Thermal power | 95 Watt |
| VID Voltage Range | 0.60 - 1.35 Volt |
Graphics | On-board graphics adapter | Nie |
Memory | Memory channels support | Quad |
| ECC | Tak |
| Memory bandwidth (max) | 42.6 gigabyte per second |
| Supported memory clock speeds | 800, 1066, 1333, 1600 megahertz |
| Supported memory types | DDR3-SDRAM |
| Maximum RAM supported | 750 gigabyte |
Processor | Stepping | C2 |
| CPU multiplier (bus/core ratio) | 30 |
| Turbo frequency (max) | 3 gigahertz |
| Bus type | QPI |
| Number of QPI links | 2 |
| L3 cache | 15 megabyte |
| Processor operating modes | 64-bit |
| System bus rate | 7.2 Gigatranfers per second |
| Processor threads | 12 |
| Processor model | E5-2640 |
| Box | Tak |
| Processor process | 32 nanometers |
| Component for | Server/Workstation |
| Processor socket | Socket R (LGA 2011) |
| Processor cores | 6 |
| Processor clock speed | 2.5 gigahertz |
| Processor family | Intel Xeon E5 |
