Processor special features | Intel VT-x with Extended Page Tables (EPT) | Tak |
| Intel TSX-NI | Nie |
| Intel Demand Based Switching | Tak |
| Intel Secure Key | Tak |
| Intel Hyper-Threading Technology | Tak |
| Intel Turbo Boost Technology | 2.0 |
| Intel vPro Technology | Tak |
| Intel Flex Memory Access | Nie |
| Enhanced Intel SpeedStep Technology | Tak |
| Intel Identity Protection Technology | Nie |
| Intel AES New Instructions | Tak |
| Intel Trusted Execution Technology | Tak |
Technical details | Embedded options available | Tak |
| Scalability | 2S |
| CPU configuration (max) | 2 |
| Supported instruction sets | AVX 2.0 |
| PCI Express slots version | 3.0 |
| Idle States | Tak |
| Thermal Monitoring Technologies | Tak |
| Execute Disable Bit | Tak |
Operational conditions | Tcase | 72.1 degrees Celcium |
Power | VID Voltage Range | 0.65 - 1.3 Volt |
Graphics | On-board graphics adapter | Nie |
Processor | Stepping | R2 |
| Turbo frequency (max) | 3.2 gigahertz |
| Bus type | QPI |
| Number of QPI links | 2 |
| Processor operating modes | 64-bit |
| System bus rate | 8 Gigatranfers per second |
| Processor threads | 16 |
| Processor model | E5-2630V3 |
| Processor process | 22 nanometers |
| Component for | Server/Workstation |
| Processor socket | LGA 2011-v3 |
| Processor cores | 8 |
| Processor clock speed | 2.4 gigahertz |
| Processor family | Intel Xeon E5 v3 |
